- Model AS-20
- Type Fiber Series
- Width 23 cm
- Height 11 cm
- Weight 20 kg
Category
-
20W
Laser Power
Laser Marking Parameters
-
Laser
The 3rd Generation Optical Fiber Laser
-
Adjustable Frequency
20KHZ - 80KHZ
-
Average Output Power
10W/20W (Optional)
-
Laser Wavelength
1064nm
Galvanometer Parameters
-
Max Processing Speed
7000mm/s
-
Repositioning accuracy
0.003mm
-
Best Resolution
0.001mm
Optical Output Characteristics
-
Scope of Marking
F=160mm，110×110mm
-
Height of Minimum Character
0.25mm
-
Minimum Line Width
0.015mm
System Property
-
System Power Supply
200W/AC220V/50HZ
-
Lift Distance
400mm
-
Working Environment
Temp：0℃ - 50℃，Humidity：5% - 90%
